Toothed

wheel

55 56 57 0

Gap ﬂag

ARST

Tick counter

ACNT

www.ti.com

Angle Functions

1005

SPNU563A–March 2018

Submit Documentation Feedback

High-End Timer (N2HET) Module

23.3.2.2.4.1 Use of the ARST Bit In Case of a Toothed Wheel Without Singularity

If a toothed wheel has no singularity (that is, no missing teeth), the ACNT must be reset when it reaches

the angle zero point. To reset the ACNT when it reaches the angle zero point, set the ARST bit to 1.

Setting the ARST bit before the reload of the tick counter will cause the HWAG to fail to reload the tick

counter. The HWAG will act like a normal tooth but the next active edge on the toothed wheel input will

reset the ACNT and TCNT and clear the ARST bit. For an example of using the ARST bit in a toothed

wheel without singularity, see Figure 23-46.

Figure 23-46. Using the ARST Bit in a Toothed Wheel Without Singularity
