Minimum offset

Immediate DF

Remote DF

25 bits

25-bit addition

32 bits

Remote DF

Immediate DF

Remote DF

32 bits

LSBs (HR data field)

25-bit addition

www.ti.com

Instruction Set

1071

SPNU563A–March 2018

Submit Documentation Feedback

High-End Timer (N2HET) Module

Figure 23-118 and Figure 23-119 illustrate the behavior of ADCNST if the remote data field is zero or is

not zero.

Figure 23-118. ADCNST Operation If Remote Data Field[31:7] Is Not Zero

Figure 23-119. ADCNST Operation if Remote Data Field [31:7] Is Zero

Execution

If (Remote Data Field Value [31:7] != 0)

Remote Data Field = Immediate Data Field + Remote Data Field;

else

Remote Data Field = Immediate Data Field + min. offset(bits C24:C0);

Jump to Next Program Address;
