High-End Timer (N2HET) Module
23.6.3.4 ADC, ADD, AND, OR, SBB, SUB, XOR
Syntax ADC | ADD | AND | OR | SBB | SUB | XOR {
src1 = { ZERO | IMM | A | B | R | S | T | ONES | REM | REMP }
src2 = { ZERO | IMM | A | B | R | S | T | ONES }
dest = { NONE | IMM | A | B | R | S | T }
[rdest = { NONE | REM | REMP }]
[brk={OFF | ON}]
[next={label | 9-bit unsigned integer}]
[remote={label | 9-bit unsigned integer}]
[control={OFF | ON}]
[init={OFF | ON}]
[smode = {LSL | CSL | LSR | CSR | RR | CRR | ASR }]
[scount = {5 bit unsigned integer}]
[data={25-bit unsigned integer}]
[hr_data={7-bit unsigned integer}]
}
Figure 23-120. ADC, ADD, AND, OR, SBB, SUB, XOR Program Field (P31:P0)
31 26 25 23 22 21 13 12 9 8 0
0 Reserved BRK Next program address 0100 Remote address
6 3 1 9 4 9
Figure 23-121. ADC, ADD, AND, OR, SBB, SUB, XOR Control Field (C31:C0)
31 27 26 25 23 22 19 18 16
Reserved Control Sub Opcode Src1 Src2
5 1 3 4 3
15 13 12 8 7 6 5 4 3 2 1 0
Smode Scount Ext. Reg Init flag 1 Rdest Register select Res.
3 5 1 1 1 2 2 1
Figure 23-122. ADC, ADD, AND, OR, SBB, SUB, XOR Data Field (D31:D0)
31 7 6 0
Data HR Data
25 7
Cycles One to three cycles, depending on operands selected. (See Table 23-80)
Register modified Selected register (A, B, R, S, T, or NONE)
Description This instruction performs the specified 32-bit arithmetic or logical operation on
operands src1 and src2, followed by an optional shift/rotate step. The result of
this operation is then stored to either an N2HET register or the immediate
data field of the instruction. In addition, the same result may be stored in a
remote data field or the least signficant bits of a remote instruction program
field (P[8:0]). Bits P[8:0] of the program field are used by most instructions
formats to hold the remote address that the instruction operates on, so the
ability to update this field programatically makes it easier to write subroutines
that operate on different data sets.
