Instruction Set

www.ti.com

1082

SPNU563A–March 2018

Submit Documentation Feedback

High-End Timer (N2HET) Module

APCNT uses the step width flags (SWF0 and SWF1) defined by SCNT to

detect period durations shorter than one step, and then disables capture.

The edge select encoding is shown in Table 23-82.

irq ON generates an interrupt when the edge state is satisfied. OFF

prevents an interrupt from being generated.

Default: OFF.

type Specifies the edge type that triggers the instruction.

Default: Fall2Fall.

Table 23-82. Edge Select Encoding for APCNT

type P7 P6 Selected Condition

Fall2Fall 1 0 Falling edge

Rise2Rise 1 1 Rising edge

period Contains the 25-bit count value from the previous APCNT period.

data 25-bit value serving as a counter.

Default: 0.
