FlexRay Module
26.3.1.1 Global Static Number 0 (GSN0)
This register contains a constant to check correctness of data transfers.
Figure 26-32. Global Static Number 0 (GSN0) [offset_TU = 00h]
31 16
Data_A
R-5432h
15 0
Data_B
R-ABCDh
LEGEND: R = Read only; -n = value after reset
Table 26-19. Global Static Number 0 (GSN0) Field Descriptions
Bit Field Value Description
31-16 Data_A 0-FFFFh Data_A
15-0 Data_B 0-FFFFh Complement of Data_A
26.3.1.2 Global Static Number 1 (GSN1)
This register contains a constant to check correctness of data transfers.
Figure 26-33. Global Static Number 1 (GSN1) [offset_TU = 04h]
31 16
Data_C
R-ABCDh
15 0
Data_D
R-5432h
LEGEND: R = Read only; -n = value after reset
Table 26-20. Global Static Number 1 (GSN1) Field Descriptions
Bit Field Value Description
31-16 Data_C 0-FFFFh Data_C
15-0 Data_D 0-FFFFh Complement of Data_C
