FlexRay Module Registers
www.ti.com
1278
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
FlexRay Module
Table 26-18. Transfer Unit Registers (continued)
Offset Address Acronym Register Description Section
0ACh TTCCR2 Trigger Transfer to Communication Controller Reset 2 Section 26.3.1.20
0B0h TTCCS3 Trigger Transfer to Communication Controller Set 3 Section 26.3.1.20
0B4h TTCCR3 Trigger Transfer to Communication Controller Reset 3 Section 26.3.1.20
0B8h TTCCS4 Trigger Transfer to Communication Controller Set 4 Section 26.3.1.20
0BCh TTCCR4 Trigger Transfer to Communication Controller Reset 4 Section 26.3.1.20
0C0h ETESMS1 Enable Transfer on Event to System Memory Set 1 Section 26.3.1.21
0C4h ETESMR1 Enable Transfer on Event to System Memory Reset 1 Section 26.3.1.21
0C8h ETESMS2 Enable Transfer on Event to System Memory Set 2 Section 26.3.1.21
0CCh ETESMR2 Enable Transfer on Event to System Memory Reset 2 Section 26.3.1.21
0D0h ETESMS3 Enable Transfer on Event to System Memory Set 3 Section 26.3.1.21
0D4h ETESMR3 Enable Transfer on Event to System Memory Reset 3 Section 26.3.1.21
0D8h ETESMS4 Enable Transfer on Event to System Memory Set 4 Section 26.3.1.21
0DCh ETESMR4 Enable Transfer on Event to System Memory Reset 4 Section 26.3.1.21
0E0h CESMS1 Clear on Event to System Memory Set 1 Section 26.3.1.22
0E4h CESMR1 Clear on Event to System Memory Reset 1 Section 26.3.1.22
0E8h CESMS2 Clear on Event to System Memory Set 2 Section 26.3.1.22
0ECh CESMR2 Clear on Event to System Memory Reset 2 Section 26.3.1.22
0F0h CESMS3 Clear on Event to System Memory Set 3 Section 26.3.1.22
0F4h CESMR3 Clear on Event to System Memory Reset 3 Section 26.3.1.22
0F8h CESMS4 Clear on Event to System Memory Set 4 Section 26.3.1.22
0FCh CESMR4 Clear on Event to System Memory Reset 4 Section 26.3.1.22
100h TSMIES1 Transfer to System Memory Interrupt Enable Set 1 Section 26.3.1.23
104h TSMIER1 Transfer to System Memory Interrupt Enable Reset 1 Section 26.3.1.23
108h TSMIES2 Transfer to System Memory Interrupt Enable Set 2 Section 26.3.1.23
10Ch TSMIER2 Transfer to System Memory Interrupt Enable Reset 2 Section 26.3.1.23
110h TSMIES3 Transfer to System Memory Interrupt Enable Set 3 Section 26.3.1.23
114h TSMIER3 Transfer to System Memory Interrupt Enable Reset 3 Section 26.3.1.23
118h TSMIES4 Transfer to System Memory Interrupt Enable Set 4 Section 26.3.1.23
11Ch TSMIER4 Transfer to System Memory Interrupt Enable Reset 4 Section 26.3.1.23
120h TCCIES1 Transfer to Communication Controller Interrupt Enable Set 1 Section 26.3.1.24
124h TCCIER1 Transfer to Communication Controller Interrupt Enable Reset 1 Section 26.3.1.24
128h TCCIES2 Transfer to Communication Controller Interrupt Enable Set 2 Section 26.3.1.24
12Ch TCCIER2 Transfer to Communication Controller Interrupt Enable Reset 2 Section 26.3.1.24
130h TCCIES3 Transfer to Communication Controller Interrupt Enable Set 3 Section 26.3.1.24
134h TCCIER3 Transfer to Communication Controller Interrupt Enable Reset 3 Section 26.3.1.24
138h TCCIES4 Transfer to Communication Controller Interrupt Enable Set 4 Section 26.3.1.24
13Ch TCCIER4 Transfer to Communication Controller Interrupt Enable Reset 4 Section 26.3.1.24
0-1FCh TCR Transfer Configuration RAM Section 26.3.1.25
200h-3FCh TCR ECC TCR ECC Test Mode Section 26.3.1.26
