www.ti.com
FlexRay Module Registers
1319
SPNU563AMarch 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
FlexRay Module
26.3.1.24 Transfer to Communication Controller Interrupt Enable Set/Reset (TCCIES[1-4]/TCCIER[1-4])
The Transfer to Communication Controller Interrupt Enable registers enables the interrupt generation on
interrupt line TU_Int0, after a transfer to the communication controller occurred (flagged in TCCO). Four
32-bit Registers reflect all 128 MBs.
The bits are set by writing 1 to TCCIESx and reset by writing 1 to TCCIERx. Writing a 0 has no effect.
Reading from both addresses will result in the same value.
Figure 26-98. Transfer to Communication Controller Interrupt Enable Set 1 (TCCIES1)
[offset_TU = 120h]
31 16
TCCIES1[31-16]
R/WS-0
15 0
TCCIES1[15-0]
R/WS-0
LEGEND: R/W = Read/Write; R = Read only; S = Set; -n = value after reset
Table 26-78. Transfer to Communication Controller Interrupt Enable Set 1 (TCCIES1)
Field Descriptions
Bit Field Value Description
31-0 TCCIES1[n] Transfer to Communication Controller Interrupt Enable Set 1. The register bits 0 to 31 correspond
to message buffers 0 to 31. Each bit of the register enables a potential interrupt, which occurs if the
corresponding TCCO1 bit is set:
0 No interrupt.
1 Interrupt is generated.
Figure 26-99. Transfer to Communication Controller Interrupt Enable Reset 1 (TCCIER1)
[offset_TU = 124h]
31 16
TCCIER1
R/WC-0
15 0
TCCIER1
R/WC-0
LEGEND: R/W = Read/Write; R = Read only; C = Clear; -n = value after reset
Table 26-79. Transfer to Communication Controller Interrupt Enable Reset 1 (TCCIER1)
Field Descriptions
Bit Field Description
31-0 TCCIER1 Transfer to Communication Controller Interrupt Enable Reset 1. The TCCIER1 register shows the identical
values to TCCIES1 if read.
