FlexRay Module Registers

www.ti.com

1324

SPNU563A–March 2018

Submit Documentation Feedback

FlexRay Module

26.3.1.26 TCR ECC Test Mode

In ECC test mode (diagnostic mode is enabled in ECC Control Register (ECC_CTRL)) the ECC

information is visible and can be read or written. The corresponding TCR entry can be found by

subtracting 0x200 from the TCR offset.

Figure 26-107. ECC Information in TCR ECC Test Mode [offset_TU_RAM = 200h-3FCh]

31 16

Reserved

R-0

15 6 5 0

Reserved ECCINF(5-0)

R-0 R/W-0

LEGEND: R/W = Read/Write; R = Read only; -n = value after reset

Table 26-87. ECC Information in TCR ECC Test Mode Field Descriptions

Bit Field Value Description

31-6 Reserved 0 Reads return 0. Writes have no effect.

5-0 ECCINF(5-0) ECC Data of TCR RAM locations.
