FlexRay Module
26.3.1.13 Transfer to Communication Controller Occurred (TCCO[1-4])
The Transfer to Communication Controller Occurred reflects the message buffer transfer status for a
VBUSP master transfer transaction from the system memory. Four 32-bit registers reflect all possible 128
message buffers.
NOTE: Writing 1 will clear a bit. Writing 0 will leave a bit unchanged.
Figure 26-48. Transfer to Communication Controller Occurred 1 (TCCO1) [offset_TU = 50h]
31 16
TCCO1[31-16]
R/W1C-0
15 0
TCCO1[15-0]
R/W1C-0
LEGEND: R/W = Read/Write; W1C = Write 1 to clear; -n = value after reset
Figure 26-49. Transfer to Communication Controller Occurred 2 (TCCO2) [offset_TU = 54h]
31 16
TCCO2[63-48]
R/W1C-0
15 0
TCCO2[47-32]
R/W1C-0
LEGEND: R/W = Read/Write; W1C = Write 1 to clear; -n = value after reset
Figure 26-50. Transfer to Communication Controller Occurred 3 (TCCO3) [offset_TU = 58h]
31 16
TCCO3[95-80]
R/W1C-0
15 0
TCCO3[79-64]
R/W1C-0
LEGEND: R/W = Read/Write; W1C = Write 1 to clear; -n = value after reset
Figure 26-51. Transfer to Communication Controller Occurred 4 (TCCO4) [offset_TU = 5Ch]
31 16
TCCO4[127-112]
R/W1C-0
15 0
TCCO4[111-96]
R/W1C-0
LEGEND: R/W = Read/Write; W1C = Write 1 to clear; -n = value after reset
