FlexRay Module Registers

1289

SPNU563A–March 2018

Submit Documentation Feedback

FlexRay Module

Table 26-30. Transfer to System Memory Occurred (TSMOn) Field Descriptions

Bit Field Value Description

31-0 TSMO(1-4)[n] Transfer to System Memory Occurred Register.

The register bits correspond to message buffers 0 to 127. Each bit of the register reflects a finished

message buffer transfer to the system memory.

0 Read: No transfer occurred.

Write: Bit is unchanged.

1 Read: Transfer occurred.

Write: Clears the bit.

Default Chapter2
