FlexRay Module Registers
www.ti.com
1302
SPNU563AMarch 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
FlexRay Module
Figure 26-64. Trigger Transfer to System Memory Set 4 (TTSMS4) [offset_TU = 98h]
31 16
TTSMS4[127-112]
R/WS-0
15 0
TTSMS4[111-96]
R/WS-0
LEGEND: R/W = Read/Write; R = Read only; S = Set; -n = value after reset
Table 26-44. Trigger Transfer to System Memory Set 4 (TTSMS4) Field Descriptions
Bit Field Value Description
31-0 TTSMS4[n] Trigger Transfer to System Memory Set 4. The register bits 0 to 31 correspond to message buffers
96 to 127. Each bit of the register controls the message buffer transfer to the system memory in the
following manner (note that only the least-significant bit of all four combined TTSM registers will be
currently scheduled for transmission).
0 No transfer request.
1 Transfer based on address defined in TBA.
Figure 26-65. Trigger Transfer to System Memory Reset 4 (TTSMR4) [offset_TU = 9Ch]
31 16
TTSMR4
R/WC-0
15 0
TTSMR4
R/WC-0
LEGEND: R/W = Read/Write; R = Read only; C = Clear; -n = value after reset
Table 26-45. Trigger Transfer to System Memory Reset 4 (TTSMR4) Field Descriptions
Bit Field Description
31-0 TTSMR4 Trigger Transfer to System Memory Reset 4. The TTSMR4 register shows the identical values to TTSMS4 if
read.
