FlexRay Module
Figure 26-78. Enable Transfer on Event to System Memory Set 3 (ETESMS3) [offset_TU = D0h]
31 16
ETESMS3[95-80]
R/WS-0
15 0
ETESMS3[79-64]
R/WS-0
LEGEND: R/W = Read/Write; R = Read only; S = Set; -n = value after reset
Table 26-58. Enable Transfer on Event to System Memory Set 3 Field Descriptions
Bit Field Value Description
31-0 ETESMS3[n] Enable Transfer on Event to System Memory Set 3. The register bits 0 to 31 correspond to
message buffers 64 to 95. Each bit of the register enables a message buffer transfer on event to
the system memory:
0 Transfer on event is disabled.
1 Transfer on event is enabled.
Figure 26-79. Enable Transfer on Event to System Memory Reset 3 (ETESMR3) [offset_TU = D4h]
31 16
ETESMR3
R/WC-0
15 0
ETESMR3
R/WC-0
LEGEND: R/W = Read/Write; R = Read only; C = Clear; -n = value after reset
Table 26-59. Enable Transfer on Event to System Memory Reset 3 (ETESMR3) Field Descriptions
Bit Field Description
31-0 ETESMR3 Enable Transfer on Event to System Memory Reset 3. The ETESMR3 register shows the identical values to
ETESMS3 if read.
