FlexRay Module Registers
www.ti.com
1308
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
FlexRay Module
Figure 26-76. Enable Transfer on Event to System Memory Set 2 (ETESMS2) [offset_TU = C8h]
31 16
ETESMS2[63-48]
R/WS-0
15 0
ETESMS2[47-32]
R/WS-0
LEGEND: R/W = Read/Write; R = Read only; S = Set; -n = value after reset
Table 26-56. Enable Transfer on Event to System Memory Set 2 Field Descriptions
Bit Field Value Description
31-0 ETESMS2[n] Enable Transfer on Event to System Memory Set 2. The register bits 0 to 31 correspond to
message buffers 32 to 63. Each bit of the register enables a message buffer transfer on event to
the system memory:
0 Transfer on event is disabled.
1 Transfer on event is enabled.
Figure 26-77. Enable Transfer on Event to System Memory Reset 2 (ETESMR2) [offset_TU = CCh]
31 16
ETESMR2
R/WC-0
15 0
ETESMR2
R/WC-0
LEGEND: R/W = Read/Write; R = Read only; C = Clear; -n = value after reset
Table 26-57. Enable Transfer on Event to System Memory Reset 2 (ETESMR2) Field Descriptions
Bit Field Description
31-0 ETESMR2 Enable Transfer on Event to System Memory Reset 2. The ETESMR2 register shows the identical values to
ETESMS2 if read.
