FlexRay Module
Figure 26-92. Transfer to System Memory Interrupt Enable Set 2 (TSMIES2) [offset_TU = 108h]
31 16
TSMIES2[63-48]
R/WS-0
15 0
TSMIES2[47-32]
R/WS-0
LEGEND: R/W = Read/Write; R = Read only; S = Set; -n = value after reset
Table 26-72. Transfer to System Memory Interrupt Enable Set 2 (TSMIES2) Field Descriptions
Bit Field Value Description
31-0 TSMIES2[n] Transfer to System Memory Interrupt Enable Set 2. The register bits 0 to 31 correspond to
message buffers 32 to 63. Each bit of the register enables a potential interrupt, which occurs if the
corresponding TSMO2 bit is set:
0 No interrupt.
1 Interrupt is generated.
Figure 26-93. Transfer to System Memory Interrupt Enable Reset 2 (TSMIER2) [offset_TU = 10Ch]
31 16
TSMIER2
R/WC-0
15 0
TSMIER2
R/WC-0
LEGEND: R/W = Read/Write; R = Read only; C = Clear; -n = value after reset
Table 26-73. Transfer to System Memory Interrupt Enable Reset 2 (TSMIER2) Field Descriptions
Bit Field Description
31-0 TSMIER2 Transfer to System Memory Interrupt Enable Reset 2. The TSMIER2 register shows the identical values to
TSMIES2 if read.
