www.ti.com

Memory Organization

135

SPNU563A–March 2018

Submit Documentation Feedback

Architecture

Table 2-5. PBIST Memory Grouping (continued)

Module RAM Group # RGS RDS Memory Type

CPGMAC_STATE_RXADDR 27 27 1 to 3 Two-port

CPGMAC_STAT_FIFO 28 27 4 to 6 Two-port

L2RAMW 29 7 1 Single-port

6 Single-port

L2RAMW 30 32 1 Single-port

6 Single-port

11 Single-port

16 Single-port

21 Single-port

26 Single-port

R5_ICACHE 31 40 1 Single-port

6 Single-port

11 Single-port

16 Single-port

R5_DCACHE 32 41 1 Single-port

6 Single-port

11 Single-port

16 Single-port

21 Single-port

26 Single-port

Reserved 33 43 1 Single-port

6 Single-port

11 Single-port

16 Single-port

Reserved 34 44 1 Single-port

6 Single-port

11 Single-port

16 Single-port

21 Single-port

26 Single-port

FRAY_TRBUF_MSGRAM 35 26 9 to 11 Single-port

CPGMAC_CPPI 36 27 7 Single-port

R5_DCACHE_Dirty 37 42 2 Single-port

Reserved 38 45 2 Single-port
