FlexRay Module
26.3.2.2.9 Timer 1 Configuration Register (T1C)
This relative timer generates an interrupt on the non maskable interrupt signal CC_tint1 after the specified
number of macroticks has expired.
Timer 1 can be activated as long as the POC is either in NORMAL_ACTIVE state or in
NORMAL_PASSIVE state. Timer 1 is deactivated when leaving NORMAL_ACTIVE state or
NORMAL_PASSIVE state except for transitions between the two states.
Before reconfiguration of the timer, the timer has to be halted first by writing bit T1RC to 0.
Figure 26-125 and Table 26-104 illustrate this register.
Figure 26-125. Timer 1 Configuration Register (T1C) [offset_CC = 48h]
31 30 29 16
Reserved TIMC
R-0 R/W-2h
15 2 1 0
Reserved T1MS T1RC
R-0 R/W-0
LEGEND: R = Read only; -n = value after reset
Table 26-104. Timer 1 Configuration Register (T1C) Field Descriptions
Bit Field Value Description
31-30 Reserved 0 Reads return 0. Writes have no effect.
29-16 TIMC Timer 1 macrotick count. When the configured macrotick count is reached the timer 1 interrupt is
generated. In case the configured macrotick count is not within the valid range, timer 1 will not
start.
Valid values:
• 2 to 16383 macroticks in continuous mode
• 1 to 16383 macroticks in single-shot mode
2h-3FFFh Continuous mode.
1h-3FFFh Single-shot mode.
15-2 Reserved 0 Reads return 0. Writes have no effect.
1 T1MS Timer 1 mode select.
0 Single-shot mode.
1 Continuous mode.
0 T1RC Timer 1 run control.
0 Timer 1 is halted.
1 Timer 1 is running.
