Texas Instruments TMS570LC4357 User Manual

www.ti.com FlexRay Module Registers
1371
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
FlexRay Module
26.3.2.3.13 GTU Configuration Register 6 (GTUC6)
The communication controller accepts modifications of the register in DEFAULT_CONFIG or CONFIG
state only.
Figure 26-140 and Table 26-119 illustrate this register.
Figure 26-140. GTU Configuration Register 6 (GTUC6) [offset_CC = B4h]
31 27 26 16
Reserved MOD*
R-0 R/W-2h
15 11 10 0
Reserved ASR*
R-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset; *These bits can be updated in DEFAULT_CONFIG or CONFIG state
only
Table 26-119. GTU Configuration Register 6 (GTUC6) Field Descriptions
Bit Field Value Description
31-27 Reserved 0 Reads return 0. Writes have no effect.
26-16 MOD 2h-783h µT Maximum oscillator drift (in microticks). Maximum drift offset between two nodes that operate with
unsynchronized clocks over one communication cycle in µT.
15-11 Reserved 0 Reads return 0. Writes have no effect.
10-0 ASR 0-753h µT Accepted startup range (in microticks). Number of microticks constituting the expanded range of
measured deviation for startup frames during integration.
26.3.2.3.14 GTU Configuration Register 7 (GTUC7)
The communication controller accepts modifications of the register in DEFAULT_CONFIG or CONFIG
state only.
Figure 26-141 and Table 26-120 illustrate this register.
Figure 26-141. GTU Configuration Register 7 (GTUC7) [offset_CC = B8h]
31 26 25 16
Reserved NSS*
R-0 R/W-2h
15 10 9 0
Reserved SSL*
R-0 R/W-4h
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset; *These bits can be updated in DEFAULT_CONFIG or CONFIG state
only
Table 26-120. GTU Configuration Register 7 (GTUC7) Field Descriptions
Bit Field Value Description
31-26 Reserved. 0 Reads return 0. Writes have no effect.
25-16 NSS 2h-3FFh Number of static slots. These bits configure the number of static slots in a cycle. At least two
coldstart nodes must be configured to startup a FlexRay network. The number of static slots
must be identical in all nodes of a cluster.
15-10 Reserved. 0 Reads return 0. Writes have no effect.
9-0 SSL 4h-293h Static slot length (in macroticks). These bits configure the duration of a static slot. The static slot
length must be identical in all nodes of a cluster.
