FlexRay Module Registers
1379
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
FlexRay Module
26.3.2.4.5 Rate Correction Value (RCV)
This register is reset when the Communication Controller leaves CONFIG state or enters STARTUP state.
Figure 26-150 and Table 26-129 illustrate this register.
Figure 26-150. Rate Correction Value Register (RCV) [offset_CC = 118h]
31 16
Reserved
R-0
15 12 11 0
Reserved RCV
R-0 R-0
LEGEND: R = Read only; -n = value after reset
Table 26-129. Rate Correction Value Register (RCV) Field Descriptions
Bit Field Value Description
31-12 Reserved 0 Reads return 0. Writes have no effect.
11-0 RCV Rate correction value (in microticks). Rate correction value (two's complement). Calculated internal rate
correction value before limitation. If the RCV value exceeds the limits defined by GTUC10.MRC, flag
SFS.RCLR is set to 1.
NOTE: The external rate correction value is added to the limited rate correction value.
26.3.2.4.6 Offset Correction Value (OCV)
Figure 26-151 and Table 26-130 illustrate this register.
Figure 26-151. Offset Correction Value Register (OCV) [offset_CC = 11Ch]
31 20 19 16
Reserved OCV
R-0 R-0
15 0
OCV
R-0
LEGEND: R = Read only; -n = value after reset
Table 26-130. Offset Correction Value Register (OCV) Field Descriptions
Bit Field Value Description
31-20 Reserved 0 Reads return 0. Writes have no effect.
19-0 OCV Offset correction value (in microticks). Offset correction value (two's complement). Calculated internal
offset correction value before limitation. If the OCV value exceeds the limits defined by GTUC10.MOC,
flag SFS.OCLR is set to 1.
NOTE: The external offset correction value is added to the limited offset correction value.
