Texas Instruments TMS570LC4357 User Manual

www.ti.com DCAN Control Registers
1455
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
Controller Area Network (DCAN) Module
Table 27-6. DCAN Control Registers (continued)
Offset Acronym Register Description Section
9Ch DCAN NWDAT12 New Data 12 Register Section 27.17.17
A0h DCAN NWDAT34 New Data 34 Register Section 27.17.17
A4h DCAN NWDAT56 New Data 56 Register Section 27.17.17
A8h DCAN NWDAT78 New Data 78 Register Section 27.17.17
ACh DCAN INTPNDX Interrupt Pending X Register Section 27.17.18
B0h DCAN INTPND12 Interrupt Pending 12 Register Section 27.17.19
B4h DCAN INTPND34 Interrupt Pending 34 Register Section 27.17.19
B8h DCAN INTPND56 Interrupt Pending 56 Register Section 27.17.19
BCh DCAN INTPND78 Interrupt Pending 78 Register Section 27.17.19
C0h DCAN MSGVALX Message Valid X Register Section 27.17.20
C4h DCAN MSGVAL12 Message Valid 12 Register Section 27.17.21
C8h DCAN MSGVAL34 Message Valid 34 Register Section 27.17.21
CCh DCAN MSGVAL56 Message Valid 56 Register Section 27.17.21
D0h DCAN MSGVAL78 Message Valid 78 Register Section 27.17.21
D8h DCAN INTMUX12 Interrupt Multiplexer 12 Register Section 27.17.22
DCh DCAN INTMUX34 Interrupt Multiplexer 34 Register Section 27.17.22
E0h DCAN INTMUX56 Interrupt Multiplexer 56 Register Section 27.17.22
E4h DCAN INTMUX78 Interrupt Multiplexer 78 Register Section 27.17.22
100h DCAN IF1CMD IF1Command Register Section 27.17.23
104h DCAN IF1MSK IF1 Mask Register Section 27.17.24
108h DCAN IF1ARB IF1 Arbitration Register Section 27.17.25
10Ch DCAN IF1MCTL IF1 Message Control Register Section 27.17.26
110h DCAN IF1DATA IF1 Data A Register Section 27.17.27
114h DCAN IF1DATB IF1 Data B Register Section 27.17.27
120h DCAN IF2CMD IF2 Command Register Section 27.17.23
124h DCAN IF2MSK IF2 Mask Register Section 27.17.24
128h DCAN IF2ARB IF2 Arbitration Register Section 27.17.25
12Ch DCAN IF2MCTL IF2 Message Control Register Section 27.17.26
130h DCAN IF2DATA IF2 Data A Register Section 27.17.27
134h DCAN IF2DATB IF2 Data B Register Section 27.17.27
140h DCAN IF3OBS IF3 Observation Register Section 27.17.28
144h DCAN IF3MSK IF3 Mask Register Section 27.17.29
148h DCAN IF3ARB IF3 Arbitration Register Section 27.17.30
14Ch DCAN IF3MCTL IF3 Message Control Register Section 27.17.31
150h DCAN IF3DATA IF3 Data A Register Section 27.17.32
154h DCAN IF3DATB IF3 Data B Register Section 27.17.32
160h DCAN IF3UPD12 IF3 Update Enable 12 Register Section 27.17.33
164h DCAN IF3UPD34 IF3 Update Enable 34 Register Section 27.17.33
168h DCAN IF3UPD56 IF3 Update Enable 56 Register Section 27.17.33
16Ch DCAN IF3UPD78 IF3 Update Enable 78 Register Section 27.17.33
1E0h DCAN TIOC CAN TX IO Control Register Section 27.17.34
1E4h DCAN RIOC CAN RX IO Control Register Section 27.17.35
