SCI/LIN Control Registers

1683

SPNU563A–March 2018

Submit Documentation Feedback

Serial Communication Interface (SCI)/ Local Interconnect Network (LIN)

Module

Table 29-18. SCI Set Interrupt Level Register (SCISETINTLVL) Field Descriptions (continued)

Bit Field Value Description

0 SET BRKDT INT LVL Set break-detect interrupt level. This bit is effective in SCI-compatible mode only.

0 Read: The interrupt level is mapped to the INT0 line.

Write: No effect.

1 Read or write: The interrupt level is mapped to the INT1 line.
