EMAC/MDIO Module
32.2.4 MII / RMII Signal Multiplexing Control
In Each of the MII and RMII interface signals are multiplexed with other functions on this microcontroller.
The application must configure the control registers in the I/O multiplexing module in order to enable the
MII/RMII functionality on the corresponding I/Os. Table 32-3 shows the byte to be configured to enable the
MDIO functions. Table 32-4 shows the byte to be configured to enable the MII or RMII functions. Please
refer to the I/O Multiplexing and Control Module (IOMM) chapter for more details on the procedure to
configure the PINMMR registers.
Table 32-3. MDIO Multiplexing Control
MDIO Signal Name Control for Selecting EMAC / MDIO Signal
MDIO_CLK PINMMR21[31:24] = 0b00000100
MDIO_D PINMMR23 [7:0] = 0b00000100
Table 32-4. MII/RMII Multiplexing Control
MII / RMII Signal Name Control for Selecting MII Signal Control for Selecting RMII Signal
MII_TXCLK PINMMR30 [23:16] = 0b00000010 -
MII_TXD[3] PINMMR30 [7:0] = 0b00000100 -
MII_TXD[2] PINMMR21 [15:8] = 0b00000100 -
MII_TXD[1] / RMII_TXD[1] PINMMR26 [7:0] = 0b00000100 PINMMR26 [7:0] = 0b00001000
MII_TXD[0] / RMII_TXD[0] PINMMR27 [7:0] = 0b00000100 PINMMR27 [7:0] = 0b00001000
MII_TXEN / RMII_TXEN PINMMR24 [23:16] = 0b00000100 PINMMR24 [23:16] = 0b00001000
MII_COL PINMMR21 [23:16] = 0b00000100 -
MII_CRS / RMII_CRSDV PINMMR31 [7:0] = 0b00000100 PINMMR31 [7:0] = 0b00001000
MII_RXCLK / RMII_50MHZ_CLK PINMMR34 [15:8] = 0b00000100 PINMMR34 [15:8] = 0b00001000
MII_RXD[3] PINMMR25 [31:24] = 0b00000100 -
MII_RXD[2] PINMMR22 [15:8] = 0b00000100 -
MII_RXD[1] / RMII_RXD[1] PINMMR34 [7:0] = 0b00000010 PINMMR34 [7:0] = 0b00000100
MII_RXD[0] / RMII_RXD[0] PINMMR33 [31:24] = 0b00000100 PINMMR33 [31:24] = 0b00001000
MII_RXDV PINMMR34 23:16] = 0b00000100 -
MII_RXER / RMII_RXER PINMMR0 [7:0] = 0b00000100 PINMMR0 [7:0] = 0b00001000
