Enhanced Pulse Width Modulator (ePWM) Module
Although all combinations are supported, not all are typical usage modes. Table 35-14 documents some
classical dead-band configurations. These modes assume that the DBCTL[IN_MODE] is configured such
that EPWMxA In is the source for both falling-edge and rising-edge delay. Enhanced, or non-traditional
modes can be achieved by changing the input signal source. The modes shown in Table 35-14 fall into
the following categories:
• Mode 1: Bypass both falling-edge delay (FED) and rising-edge delay (RED)
Allows you to fully disable the dead-band submodule from the PWM signal path.
• Mode 2-5: Classical Dead-Band Polarity Settings:
These represent typical polarity configurations that should address all the active high/low modes
required by available industry power switch gate drivers. The waveforms for these typical cases are
shown in Figure 35-29. Note that to generate equivalent waveforms to Figure 35-29, configure the
action-qualifier submodule to generate the signal as shown for EPWMxA.
• Mode 6: Bypass rising-edge-delay and Mode 7: Bypass falling-edge-delay
Finally the last two entries in Table 35-14 show combinations where either the falling-edge-delay (FED)
or rising-edge-delay (RED) blocks are bypassed.
Table 35-14. Classical Dead-Band Operating Modes
Mode Mode Description
DBCTL[POLSEL] DBCTL[OUT_MODE]
S3 S2 S1 S0
1 EPWMxA and EPWMxB Passed Through (No Delay) X X 0 0
2 Active High Complementary (AHC) 1 0 1 1
3 Active Low Complementary (ALC) 0 1 1 1
4 Active High (AH) 0 0 1 1
5 Active Low (AL) 1 1 1 1
6
EPWMxA Out = EPWMxA In (No Delay) 0 or 1 0 or 1 0 1
EPWMxB Out = EPWMxA In with Falling Edge Delay
7
EPWMxA Out = EPWMxA In with Rising Edge Delay 0 or 1 0 or 1 1 0
EPWMxB Out = EPWMxB In with No Delay
