Enhanced Pulse Width Modulator (ePWM) Module
35.4.3.4 Action-Qualifier Continuous Force Register (AQCSFRC)
Figure 35-74. Action-Qualifier Continuous Software Force Register (AQCSFRC) [offset = 1Eh]
15 8
Reserved
R-0
7 4 3 2 1 0
Reserved CSFB CSFA
R-0 R/W-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 35-34. Action-qualifier Continuous Software Force Register (AQCSFRC) Field Descriptions
Bits Name Value Description
15-4 Reserved 0 Reserved
3-2 CSFB Continuous Software Force on Output B.
In immediate mode, a continuous force takes effect on the next TBCLK edge.
In shadow mode, a continuous force takes effect on the next TBCLK edge after a shadow load into
the active register. To configure shadow mode, use AQSFRC[RLDCSF].
0 Forcing disabled, that is, has no effect.
1h Forces a continuous low on output B.
2h Forces a continuous high on output.
3h Software forcing is disabled and has no effect.
1-0 CSFA Continuous Software Force on Output A.
In immediate mode, a continuous force takes effect on the next TBCLK edge.
In shadow mode, a continuous force takes effect on the next TBCLK edge after a shadow load into
the active register.
0 Forcing disabled, that is, has no effect.
1h Forces a continuous low on output A.
2h Forces a continuous high on output A.
3h Software forcing is disabled and has no effect.
