ePWM Registers
www.ti.com
2084
SPNU563AMarch 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
Enhanced Pulse Width Modulator (ePWM) Module
35.4.4.2 Dead-Band Generator Falling Edge Delay Register (DBFED)
Figure 35-76. Dead-Band Generator Falling Edge Delay Register (DBFED) [offset = 20h]
15 10 9 8
Reserved DEL
R-0 R/W-0
7 0
DEL
R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 35-36. Dead-Band Generator Falling Edge Delay Register (DBFED) Field Descriptions
Bits Name Description
15-10 Reserved Reserved
9-0 DEL Falling Edge Delay Count. 10-bit counter.
35.4.4.3 Dead-Band Generator Rising Edge Delay Register (DBRED)
Figure 35-77. Dead-Band Generator Rising Edge Delay Register (DBRED) [offset = 22h]
15 10 9 8
Reserved DEL
R-0 R/W-0
7 0
DEL
R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 35-37. Dead-Band Generator Rising Edge Delay Register (DBRED) Field Descriptions
Bits Name Description
15-10 Reserved Reserved
9-0 DEL Rising Edge Delay Count. 10-bit counter.
