Enhanced Pulse Width Modulator (ePWM) Module
35.4.5.2 Trip-Zone Select Register (TZSEL)
Figure 35-79. Trip-Zone Select Register (TZSEL) [offset = 26h]
15 14 13 12 11 10 9 8
DCBEVT1 DCAEVT1 OSHT6 OSHT5 OSHT4 OSHT3 OSHT2 OSHT1
R-0 R-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
7 6 5 4 3 2 1 0
DCBEVT2 DCAEVT2 CBC6 CBC5 CBC4 CBC3 CBC2 CBC1
R-0 R-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 35-39. Trip-Zone Submodule Select Register (TZSEL) Field Descriptions
Bits Name Value Description
One-Shot (OSHT) Trip-zone enable/disable. When any of the enabled pins go low, a one-shot trip event occurs for this ePWM
module. When the event occurs, the action defined in the TZCTL register is taken on the EPWMxA and EPWMxB outputs. The
one-shot trip condition remains latched until the user clears the condition via the TZCLR register.
15 DCBEVT1 Digital Compare Output B Event 1 Select.
0 Disable DCBEVT1 as one-shot-trip source for this ePWM module.
1 Enable DCBEVT1 as one-shot-trip source for this ePWM module.
14 DCAEVT1 Digital Compare Output A Event 1 Select.
0 Disable DCAEVT1 as one-shot-trip source for this ePWM module.
1 Enable DCAEVT1 as one-shot-trip source for this ePWM module.
13 OSHT6 Trip-zone 6 (TZ6) Select.
0 Disable TZ6 as a one-shot trip source for this ePWM module.
1 Enable TZ6 as a one-shot trip source for this ePWM module.
12 OSHT5 Trip-zone 5 (TZ5) Select.
0 Disable TZ5 as a one-shot trip source for this ePWM module.
1 Enable TZ5 as a one-shot trip source for this ePWM module.
11 OSHT4 Trip-zone 4 (TZ4) Select.
0 Disable TZ4 as a one-shot trip source for this ePWM module.
1 Enable TZ4 as a one-shot trip source for this ePWM module.
10 OSHT3 Trip-zone 3 (TZ3) Select.
0 Disable TZ3 as a one-shot trip source for this ePWM module.
1 Enable TZ3 as a one-shot trip source for this ePWM module.
9 OSHT2 Trip-zone 2 (TZ2) Select.
0 Disable TZ2 as a one-shot trip source for this ePWM module.
1 Enable TZ2 as a one-shot trip source for this ePWM module.
8 OSHT1 Trip-zone 1 (TZ1) Select.
0 Disable TZ1 as a one-shot trip source for this ePWM module.
1 Enable TZ1 as a one-shot trip source for this ePWM module.
Cycle-by-Cycle (CBC) Trip-zone enable/disable. When any of the enabled pins go low, a cycle-by-cycle trip event occurs for this
ePWM module. When the event occurs, the action defined in the TZCTL register is taken on the EPWMxA and EPWMxB outputs. A
cycle-by-cycle trip condition is automatically cleared when the time-base counter reaches zero.
7 DCBEVT2 Digital Compare Output B Event 2 Select.
0 Disable DCBEVT2 as a CBC trip source for this ePWM module.
1 Enable DCBEVT2 as a CBC trip source for this ePWM module.
6 DCAEVT2 Digital Compare Output A Event 2 Select.
0 Disable DCAEVT2 as a CBC trip source for this ePWM module.
1 Enable DCAEVT2 as a CBC trip source for this ePWM module.
