Enhanced Pulse Width Modulator (ePWM) Module
Table 35-39. Trip-Zone Submodule Select Register (TZSEL) Field Descriptions (continued)
Bits Name Value Description
5 CBC6 Trip-zone 6 (TZ6) Select.
0 Disable TZ6 as a CBC trip source for this ePWM module.
1 Enable TZ6 as a CBC trip source for this ePWM module.
4 CBC5 Trip-zone 5 (TZ5) Select.
0 Disable TZ5 as a CBC trip source for this ePWM module.
1 Enable TZ5 as a CBC trip source for this ePWM module.
3 CBC4 Trip-zone 4 (TZ4) Select.
0 Disable TZ4 as a CBC trip source for this ePWM module.
1 Enable TZ4 as a CBC trip source for this ePWM module.
2 CBC3 Trip-zone 3 (TZ3) Select.
0 Disable TZ3 as a CBC trip source for this ePWM module.
1 Enable TZ3 as a CBC trip source for this ePWM module.
1 CBC2 Trip-zone 2 (TZ2) Select.
0 Disable TZ2 as a CBC trip source for this ePWM module.
1 Enable TZ2 as a CBC trip source for this ePWM module.
0 CBC1 Trip-zone 1 (TZ1) Select.
0 Disable TZ1 as a CBC trip source for this ePWM module.
1 Enable TZ1 as a CBC trip source for this ePWM module.
