Enhanced Pulse Width Modulator (ePWM) Module
35.4.5.3 Trip-Zone Enable Interrupt Register (TZEINT)
Figure 35-80. Trip-Zone Enable Interrupt Register (TZEINT) [offset = 28h]
15 8
Reserved
R -0
7 6 5 4 3 2 1 0
Reserved DCBEVT2 DCBEVT1 DCAEVT2 DCAEVT1 OST CBC Reserved
R-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 35-40. Trip-Zone Enable Interrupt Register (TZEINT) Field Descriptions
Bits Name Value Description
15-3 Reserved 0 Reserved
6 DCBEVT2 Digital Comparator Output B Event 2 Interrupt Enable.
0 Disabled
1 Enabled
5 DCBEVT1 Digital Comparator Output B Event 1 Interrupt Enable.
0 Disabled
1 Enabled
4 DCAEVT2 Digital Comparator Output A Event 2 Interrupt Enable.
0 Disabled
1 Enabled
3 DCAEVT1 Digital Comparator Output A Event 1 Interrupt Enable.
0 Disabled
1 Enabled
2 OST Trip-zone One-Shot Interrupt Enable.
0 Disable one-shot interrupt generation.
1 Enable Interrupt generation; a one-shot trip event will cause a EPWMx_TZINT VIM interrupt.
1 CBC Trip-zone Cycle-by-Cycle Interrupt Enable.
0 Disable cycle-by-cycle interrupt generation.
1 Enable interrupt generation; a cycle-by-cycle trip event will cause an EPWMx_TZINT VIM interrupt.
0 Reserved 0 Reserved
