Enhanced Pulse Width Modulator (ePWM) Module
35.4.5.7 Trip-Zone Force Register (TZFRC)
Figure 35-84. Trip-Zone Force Register (TZFRC) [offset = 32h]
15 8
Reserved
R-0
7 6 5 4 3 2 1 0
Reserved DCBEVT2 DCBEVT1 DCAEVT2 DCAEVT1 OST CBC Reserved
R-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R- 0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 35-44. Trip-Zone Force Register (TZFRC) Field Descriptions
Bits Name Value Description
15-7 Reserved 0 Reserved
6 DCBEVT2 Force Flag for Digital Compare Output B Event 2.
0 Writing 0 has no effect. This bit always reads back 0.
1 Writing 1 forces the DCBEVT2 event trip condition and sets the TZFLG[DCBEVT2] bit.
5 DCBEVT1 Force Flag for Digital Compare Output B Event 1.
0 Writing 0 has no effect. This bit always reads back 0.
1 Writing 1 forces the DCBEVT1 event trip condition and sets the TZFLG[DCBEVT1] bit.
4 DCAEVT2 Force Flag for Digital Compare Output A Event 2.
0 Writing 0 has no effect. This bit always reads back 0.
1 Writing 1 forces the DCAEVT2 event trip condition and sets the TZFLG[DCAEVT2] bit.
3 DCAEVT1 Force Flag for Digital Compare Output A Event 1.
0 Writing 0 has no effect. This bit always reads back 0
1 Writing 1 forces the DCAEVT1 event trip condition and sets the TZFLG[DCAEVT1] bit.
2 OST Force a One-Shot Trip Event via Software.
0 Writing of 0 is ignored. Always reads back a 0.
1 Forces a one-shot trip event and sets the TZFLG[OST] bit.
1 CBC Force a Cycle-by-Cycle Trip Event via Software.
0 Writing of 0 is ignored. Always reads back a 0.
1 Forces a cycle-by-cycle trip event and sets the TZFLG[CBC] bit.
0 Reserved 0 Reserved
