Enhanced Pulse Width Modulator (ePWM) Module
35.4.6 Event-Trigger Submodule Registers
35.4.6.1 Event-Trigger Selection Register (ETSEL)
Figure 35-85. Event-Trigger Selection Register (ETSEL) [offset = 30h]
15 14 12 11 10 8
SOCBEN SOCBSEL SOCAEN SOCASEL
R/W-0 R/W-0 R/W-0 R/W-0
7 4 3 2 0
Reserved INTEN INTSEL
R-0 R/W-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 35-45. Event-Trigger Selection Register (ETSEL) Field Descriptions
Bits Name Value Description
15 SOCBEN Enable the ADC Start of Conversion B (EPWMxSOCB) Pulse.
0 Disable EPWMxSOCB.
1 Enable EPWMxSOCB pulse.
14-12 SOCBSEL EPWMxSOCB Selection Options.
These bits determine when a EPWMxSOCB pulse will be generated.
0 Enable DCBEVT1.soc event.
1h Enable event time-base counter equal to zero. (TBCTR = 0x0000).
2h Enable event time-base counter equal to period (TBCTR = TBPRD).
3h Enable event time-base counter equal to zero or period (TBCTR = 0x0000 or TBCTR = TBPRD).
This mode is useful in up-down count mode.
4h Enable event time-base counter equal to CMPA when the timer is incrementing.
5h Enable event time-base counter equal to CMPA when the timer is decrementing.
6h Enable event: time-base counter equal to CMPB when the timer is incrementing.
7h Enable event: time-base counter equal to CMPB when the timer is decrementing.
11 SOCAEN Enable the ADC Start of Conversion A (EPWMxSOCA) Pulse.
0 Disable EPWMxSOCA.
1 Enable EPWMxSOCA pulse.
10-8 SOCASEL EPWMxSOCA Selection Options.
These bits determine when a EPWMxSOCA pulse will be generated.
0 Enable DCAEVT1.soc event.
1h Enable event time-base counter equal to zero. (TBCTR = 0x0000).
2h Enable event time-base counter equal to period (TBCTR = TBPRD).
3h Enable event time-base counter equal to zero or period (TBCTR = 0x0000 or TBCTR = TBPRD).
This mode is useful in up-down count mode.
4h Enable event time-base counter equal to CMPA when the timer is incrementing.
5h Enable event time-base counter equal to CMPA when the timer is decrementing.
6h Enable event: time-base counter equal to CMPB when the timer is incrementing.
7h Enable event: time-base counter equal to CMPB when the timer is decrementing.
7-4 Reserved 0 Reserved
3 INTEN Enable ePWM Interrupt (EPWMx_INT) Generation.
0 Disable EPWMx_INT generation.
1 Enable EPWMx_INT generation.
