Enhanced Pulse Width Modulator (ePWM) Module
Table 35-45. Event-Trigger Selection Register (ETSEL) Field Descriptions (continued)
Bits Name Value Description
2-0 INTSEL ePWM Interrupt (EPWMx_INT) Selection Options.
0 Reserved
1h Enable event time-base counter equal to zero. (TBCTR = 0x0000).
2h Enable event time-base counter equal to period (TBCTR = TBPRD).
3h Enable event time-base counter equal to zero or period (TBCTR = 0x0000 or TBCTR = TBPRD).
This mode is useful in up-down count mode.
4h Enable event time-base counter equal to CMPA when the timer is incrementing.
5h Enable event time-base counter equal to CMPA when the timer is decrementing.
6h Enable event: time-base counter equal to CMPB when the timer is incrementing.
7h Enable event: time-base counter equal to CMPB when the timer is decrementing.
35.4.6.2 Event-Trigger Flag Register (ETFLG)
Figure 35-86. Event-Trigger Flag Register (ETFLG) [offset = 34h]
15 8
Reserved
R-0
7 4 3 2 1 0
Reserved SOCB SOCA Reserved INT
R-0 R-0 R-0 R-0 R-0
LEGEND: R = Read only; -n = value after reset
Table 35-46. Event-Trigger Flag Register (ETFLG) Field Descriptions
Bits Name Value Description
15-4 Reserved 0 Reserved
3 SOCB Latched ePWM ADC Start-of-Conversion B (EPWMxSOCB) Status Flag.
0 No EPWMxSOCB event occurred.
1 A start of conversion pulse was generated on EPWMxSOCB. The EPWMxSOCB output will
continue to be generated even if the flag bit is set.
2 SOCA Latched ePWM ADC Start-of-Conversion A (EPWMxSOCA) Status Flag.
Unlike the ETFLG[INT] flag, the EPWMxSOCA output will continue to pulse even if the flag bit is
set.
0 No event occurred.
1 A start of conversion pulse was generated on EPWMxSOCA. The EPWMxSOCA output will
continue to be generated even if the flag bit is set.
1 Reserved 0 Reserved
0 INT Latched ePWM Interrupt (EPWMx_INT) Status Flag.
0 No event occurred.
1 An ePWMx interrupt (EWPMx_INT) was generated. No further interrupts will be generated until the
flag bit is cleared. Up to one interrupt can be pending while the ETFLG[INT] bit is still set. If an
interrupt is pending, it will not be generated until after the ETFLG[INT] bit is cleared. Refer to
Figure 35-41.
