Enhanced Pulse Width Modulator (ePWM) Module
35.4.6.3 Event-Trigger Prescale Register (ETPS)
Figure 35-87. Event-Trigger Prescale Register (ETPS) [offset = 36h]
15 14 13 12 11 10 9 8
SOCBCNT SOCBPRD SOCACNT SOCAPRD
R-0 R/W-0 R-0 R/W-0
7 4 3 2 1 0
Reserved INTCNT INTPRD
R-0 R-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 35-47. Event-Trigger Prescale Register (ETPS) Field Descriptions
Bits Name Value Description
15-14 SOCBCNT ePWM ADC Start-of-Conversion B Event (EPWMxSOCB) Counter Register.
These bits indicate how many selected ETSEL[SOCBSEL] events have occurred.
0 No events have occurred.
1h 1 event has occurred.
2h 2 events have occurred.
3h 3 events have occurred.
13-12 SOCBPRD ePWM ADC Start-of-Conversion B Event (EPWMxSOCB) Period Select.
These bits determine how many selected ETSEL[SOCBSEL] events need to occur before an
EPWMxSOCB pulse is generated. To be generated, the pulse must be enabled (ETSEL[SOCBEN]
= 1). The SOCB pulse will be generated even if the status flag is set from a previous start of
conversion (ETFLG[SOCB] = 1). Once the SOCB pulse is generated, the ETPS[SOCBCNT] bits will
automatically be cleared.
0 Disable the SOCB event counter. No EPWMxSOCB pulse will be generated.
1h Generate the EPWMxSOCB pulse on the first event: ETPS[SOCBCNT] = 0,1.
2h Generate the EPWMxSOCB pulse on the second event: ETPS[SOCBCNT] = 1,0.
3h Generate the EPWMxSOCB pulse on the third event: ETPS[SOCBCNT] = 1,1.
11-10 SOCACNT ePWM ADC Start-of-Conversion A Event (EPWMxSOCA) Counter Register.
These bits indicate how many selected ETSEL[SOCASEL] events have occurred.
0 No events have occurred.
1h 1 event has occurred.
2h 2 events have occurred.
3h 3 events have occurred.
9-8 SOCAPRD ePWM ADC Start-of-Conversion A Event (EPWMxSOCA) Period Select.
These bits determine how many selected ETSEL[SOCASEL] events need to occur before an
EPWMxSOCA pulse is generated. To be generated, the pulse must be enabled (ETSEL[SOCAEN]
= 1). The SOCA pulse will be generated even if the status flag is set from a previous start of
conversion (ETFLG[SOCA] = 1). Once the SOCA pulse is generated, the ETPS[SOCACNT] bits will
automatically be cleared.
0 Disable the SOCA event counter. No EPWMxSOCA pulse will be generated.
1h Generate the EPWMxSOCA pulse on the first event: ETPS[SOCACNT] = 0,1.
2h Generate the EPWMxSOCA pulse on the second event: ETPS[SOCACNT] = 1,0.
3h Generate the EPWMxSOCA pulse on the third event: ETPS[SOCACNT] = 1,1.
7-4 Reserved 0 Reserved
