Enhanced Pulse Width Modulator (ePWM) Module
Table 35-47. Event-Trigger Prescale Register (ETPS) Field Descriptions (continued)
Bits Name Value Description
3-2 INTCNT ePWM Interrupt Event (EPWMx_INT) Counter Register.
These bits indicate how many selected ETSEL[INTSEL] events have occurred. These bits are
automatically cleared when an interrupt pulse is generated. If interrupts are disabled, ETSEL[INT] =
0 or the interrupt flag is set, ETFLG[INT] = 1, the counter will stop counting events when it reaches
the period value ETPS[INTCNT] = ETPS[INTPRD].
0 No events have occurred.
1h 1 event has occurred.
2h 2 events have occurred.
3h 3 events have occurred.
1-0 INTPRD ePWM Interrupt (EPWMx_INT) Period Select.
These bits determine how many selected ETSEL[INTSEL] events need to occur before an interrupt
is generated. To be generated, the interrupt must be enabled (ETSEL[INT] = 1). If the interrupt
status flag is set from a previous interrupt (ETFLG[INT] = 1) then no interrupt will be generated until
the flag is cleared via the ETCLR[INT] bit. This allows for one interrupt to be pending while another
is still being serviced. Once the interrupt is generated, the ETPS[INTCNT] bits will automatically be
cleared.
Writing a INTPRD value that is the same as the current counter value will trigger an interrupt if it is
enabled and the status flag is clear.
Writing a INTPRD value that is less than the current counter value will result in an undefined state.
If a counter event occurs at the same instant as a new zero or non-zero INTPRD value is written,
the counter is incremented.
0 Disable the interrupt event counter. No interrupt will be generated and ETFRC[INT] is ignored.
1h Generate an interrupt on the first event INTCNT = 01 (first event).
2h Generate interrupt on ETPS[INTCNT] = 1,0 (second event).
3h Generate interrupt on ETPS[INTCNT] = 1,1 (third event).
