Texas Instruments TMS570LC4357 User Manual

Control of Multiplexed Inputs www.ti.com
304
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
I/O Multiplexing and Control Module (IOMM)
Table 6-1. Multiplexing for Outputs on 337ZWT Package
Address
Offset
337ZWT
BALL
Default Function Selection
Bit
Alternate Function 1 Selection
Bit
Alternate Function 2 Selection
Bit
Alternate Function 3 Selection
Bit
Alternate Function 4 Selection
Bit
Alternate Function 5 Selection
Bit
110h N19 AD1EVT 0[0] MII_RX_ER 0[2] RMII_RX_ER 0[3] nTZ1_1 0[5]
D4 EMIF_ADDR[00] 0[8] N2HET2[01] 0[10]
D5 EMIF_ADDR[01] 0[16] N2HET2[03] 0[18]
C4 EMIF_ADDR[06] 0[24] RTP_DATA[13] 0[25] N2HET2[11] 0[26]
114h C5 EMIF_ADDR[07] 1[0] RTP_DATA[12] 1[1] N2HET2[13] 1[2]
C6 EMIF_ADDR[08] 1[8] RTP_DATA[11] 1[9] N2HET2[15] 1[10]
C7 EMIF_ADDR[09] 1[16] RTP_DATA[10] 1[17]
C8 EMIF_ADDR[10] 1[24] RTP_DATA[09] 1[25]
118h C9 EMIF_ADDR[11] 2[0] RTP_DATA[08] 2[1]
C10 EMIF_ADDR[12] 2[8] RTP_DATA[06] 2[9]
C11 EMIF_ADDR[13] 2[16] RTP_DATA[05] 2[17]
C12 EMIF_ADDR[14] 2[24] RTP_DATA[04] 2[25]
11Ch C13 EMIF_ADDR[15] 3[0] RTP_DATA[03] 3[1]
D14 EMIF_ADDR[16] 3[8] RTP_DATA[02] 3[9]
C14 EMIF_ADDR[17] 3[16] RTP_DATA[01] 3[17]
D15 EMIF_ADDR[18] 3[24] RTP_DATA[00] 3[25]
120h C15 EMIF_ADDR[19] 4[0] RTP_nENA 4[1]
C16 EMIF_ADDR[20] 4[8] RTP_nSYNC 4[9]
C17 EMIF_ADDR[21] 4[16] RTP_CLK 4[17]
124h-12Ch Reserved
130h PINMMR8[23:0] are reserved
D16 EMIF_BA[1] 8[24] 8[25] N2HET2[05] 8[26]
134h K3 RESERVED 9[0] EMIF_CLK 9[1] ECLK2 9[2]
R4 EMIF_nCAS 9[8] GIOB[3] 9[10]
N17 EMIF_nCS[0] 9[16] RTP_DATA[15] 9[17] N2HET2[07] 9[18]
L17 EMIF_nCS[2] 9[24] GIOB[4] 9[26]
138h K17 EMIF_nCS[3] 10[0] RTP_DATA[14] 10[1] N2HET2[09] 10[2]
M17 EMIF_nCS[4] 10[8] RTP_DATA[07] 10[9] GIOB[5] 10[10]
R3 EMIF_nRAS 10[16] GIOB[6] 10[18]
P3 EMIF_nWAIT 10[24] GIOB[7] 10[26]
13Ch D17 EMIF_nWE 11[0] EMIF_RNW 11[1]
E9 ETMDATA[08] 11[8] EMIF_ADDR[05] 11[9]
E8 ETMDATA[09] 11[16] EMIF_ADDR[04] 11[17]
E7 ETMDATA[10] 11[24] EMIF_ADDR[03] 11[25]
140h E6 ETMDATA[11] 12[0] EMIF_ADDR[02] 12[1]
E13 ETMDATA[12] 12[8] EMIF_BA[0] 12[9]
E12 ETMDATA[13] 12[16] EMIF_nOE 12[17]
E11 ETMDATA[14] 12[24] EMIF_nDQM[1] 12[25]
