www.ti.com Control of Multiplexed Inputs
305
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
I/O Multiplexing and Control Module (IOMM)
Table 6-1. Multiplexing for Outputs on 337ZWT Package (continued)
Address
Offset
337ZWT
BALL
Default Function Selection
Bit
Alternate Function 1 Selection
Bit
Alternate Function 2 Selection
Bit
Alternate Function 3 Selection
Bit
Alternate Function 4 Selection
Bit
Alternate Function 5 Selection
Bit
144h E10 ETMDATA[15] 13[0] EMIF_nDQM[0] 13[1]
K15 ETMDATA[16] 13[8] EMIF_DATA[00] 13[9]
L15 ETMDATA[17] 13[16] EMIF_DATA[01] 13[17]
M15 ETMDATA[18] 13[24] EMIF_DATA[02] 13[25]
148h N15 ETMDATA[19] 14[0] EMIF_DATA[03] 14[1]
E5 ETMDATA[20] 14[8] EMIF_DATA[04] 14[9]
F5 ETMDATA[21] 14[16] EMIF_DATA[05] 14[17]
G5 ETMDATA[22] 14[24] EMIF_DATA[06] 14[25]
14Ch K5 ETMDATA[23] 15[0] EMIF_DATA[07] 15[1]
L5 ETMDATA[24] 15[8] EMIF_DATA[08] 15[9] N2HET2[24] 15[10] MIBSPI5NCS[4] 15[11]
M5 ETMDATA[25] 15[16] EMIF_DATA[09] 15[17] N2HET2[25] 15[18] MIBSPI5NCS[5] 15[19]
N5 ETMDATA[26] 15[24] EMIF_DATA[10] 15[25] N2HET2[26] 15[26]
150h P5 ETMDATA[27] 16[0] EMIF_DATA[11] 16[1] N2HET2[27] 16[2]
R5 ETMDATA[28] 16[8] EMIF_DATA[12] 16[9] N2HET2[28] 16[10] GIOA[0] 16[11]
R6 ETMDATA[29] 16[16] EMIF_DATA[13] 16[17] N2HET2[29] 16[18] GIOA[1] 16[19]
R7 ETMDATA[30] 16[24] EMIF_DATA[14] 16[25] N2HET2[30] 16[26] GIOA[3] 16[27]
154h R8 ETMDATA[31] 17[0] EMIF_DATA[15] 17[1] N2HET2[31] 17[2] GIOA[4] 17[3]
R9 ETMTRACECLKIN 17[8] EXTCLKIN2 17[9] GIOA[5] 17[11]
R10 ETMTRACECLKOUT 17[16] GIOA[6] 17[19]
R11 ETMTRACECTL 17[24] GIOA[7] 17[27]
158h B15 FRAYTX1 18[0] GIOA[2] 18[3]
B8 FRAYTX2 18[8] GIOB[0] 18[11]
B16 FRAYTXEN1 18[16] GIOB[1] 18[19]
B9 FRAYTXEN2 18[24] GIOB[2] 18[27]
15Ch C1 GIOA[2] 19[0] N2HET2[00] 19[2] eQEP2I 19[5]
E1 GIOA[3] 19[8] N2HET2[02] 19[10]
B5 GIOA[5] 19[16] EXTCLKIN 19[19] ePWM1A 19[21]
H3 GIOA[6] 19[24] N2HET2[04] 19[26] ePWM1B 19[29]
160h M1 GIOA[7] 20[0] N2HET2[06] 20[2] ePWM2A 20[5]
F2 GIOB[2] 20[8] DCAN4TX 20[11]
W10 GIOB[3] 20[16] DCAN4RX 20[19]
J2 GIOB[6] 20[24] nERROR1 20[25]
164h F1 GIOB[7] 21[0] nERROR2 21[1] nTZ1_2 21[5]
R2 MIBSPI1NCS[0] 21[8] MIBSPI1SOMI[1] 21[9] MII_TXD[2] 21[10] ECAP6 21[13]
F3 MIBSPI1NCS[1] 21[16] MII_COL 21[18] N2HET1[17] 21[19] eQEP1S 21[21]
G3 MIBSPI1NCS[2] 21[24] MDIO 21[26] N2HET1[19] 21[27]
