time

Clock0

reload

An error signal is generated since Count1

Clock1

Valid0

Error

Count1 does not count down

due to an inactive clock 1

Count0

Count1

does not reach 0 in the Valid0 window.

time

Clock0

reload

Count0

Counter1 reaches 0 before

Clock1

Valid0

Error

Counter0 reaches 0

Count1

Module Operation

www.ti.com

546

SPNU563A–March 2018

Submit Documentation Feedback

Dual-Clock Comparator (DCC) Module

Figure 15-4. Clock1 Faster Than Clock0 - Results in an Error and Stops Counting

Figure 15-5. Clock1 Not Present - Results in an Error and Stops Counting
