Direct Memory Access Controller (DMA) Module
20.3.1.21 Port Assignment Register 0 (PAR0)
Figure 20-39. Port Assignment Register 0 (PAR0) [offset = 94h]
31 30 28 27 26 24 23 22 20 19 18 16
Rsvd CH0PA Rsvd CH1PA Rsvd CH2PA Rsvd CH3PA
R-0 R/WP-0 R-0 R/WP-0 R-0 R/WP-0 R-0 R/WP-0
15 14 12 11 10 8 7 6 4 3 2 0
Rsvd CH4PA Rsvd CH5PA Rsvd CH6PA Rsvd CH7PA
R-0 R/WP-0 R-0 R/WP-0 R-0 R/WP-0 R-0 R/WP-0
LEGEND: R/W = Read/Write; R = Read only; WP = Write in privilege mode only; -n = value after reset
Table 20-29. Port Assignment Register 0 (PAR0) Field Descriptions
Bit Field Value Description
31 Reserved 0 Reads return 0. Writes have no effect.
30-28 CH0PA These bit fields determine to which port(s) channel 0 is assigned.
1h Port A and B combined, A read/B write
2h Port A only
3h Port B only
Others Port A and B combined, B read/A write
27 Reserved 0 Reads return 0. Writes have no effect.
26-24 CH1PA 0-7h These bit fields determine to which port channel 1 is assigned. Refer to CH0PA for bit value
descriptions.
23 Reserved 0 Reads return 0. Writes have no effect.
22-20 CH2PA 0-7h These bit fields determine to which port channel 2 is assigned. Refer to CH0PA for bit value
descriptions.
19 Reserved 0 Reads return 0. Writes have no effect.
18-16 CH3PA 0-7h These bit fields determine to which port channel 3 is assigned. Refer to CH0PA for bit value
descriptions.
15 Reserved 0 Reads return 0. Writes have no effect.
14-12 CH4PA 0-7h These bit fields determine to which port channel 4 is assigned. Refer to CH0PA for bit value
descriptions.
11 Reserved 0 Reads return 0. Writes have no effect.
10-8 CH5PA 0-7h These bit fields determine to which port channel 5 is assigned. Refer to CH0PA for bit value
descriptions.
7 Reserved 0 Reads return 0. Writes have no effect.
6-4 CH6PA 0-7h These bit fields determine to which port channel 6 is assigned. Refer to CH0PA for bit value
descriptions.
3 Reserved 0 Reads return 0. Writes have no effect.
2-0 CH7PA 0-7h These bit fields determine to which port channel 7 is assigned. Refer to CH0PA for bit value
descriptions.
