Control Registers and Control Packets
www.ti.com
756
SPNU563AMarch 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
Direct Memory Access Controller (DMA) Module
20.3.1.47 FTCB Interrupt Channel Offset Register (FTCBOFFSET)
Figure 20-64. FTCB Interrupt Channel Offset Register (FTCBOFFSET) [offset = 160h]
31 16
Reserved
R-0
15 8 7 6 5 0
Reserved sbz sbz FTCB
R-0 R-0 R-0 R-0
LEGEND: R = Read only; -n = value after reset
Table 20-54. FTCB Interrupt Channel Offset Register (FTCBOFFSET) Field Descriptions
Bit Field Value Description
31-16 Reserved 0 Reads return 0. Writes have no effect.
7-6 sbz 0 These bits should always be programmed as zero.
5-0 FTCB Channel causing FTC interrupt Group B. These bits contain the channel number of the pending interrupt
for Group B if the corresponding interrupt enable is set.
Note: Reading this location clears the corresponding interrupt pending flag (see
Section 20.3.1.38) with the highest priority.
0 No interrupt is pending.
1h Channel 0 is causing the pending interrupt Group B.
: :
20h Channel 31 is causing the pending interrupt Group B.
21h-
3Fh
Reserved
