Table 20-71. DMA Memory Protection Control Register 1 (DMAMPCTRL1) Field Descriptions (continued)
Bit Field Value Description
15-13 Reserved 0 Reads return 0. Writes have no effect.
12 INT1AB Interrupt assignment of region 1 to Group A or Group B.
0 The interrupt is routed to the VIM (Group A).
1 The interrupt is routed to the second CPU (Group B).
11 INT1ENA Interrupt enable of region 1.
0 The interrupt is disabled.
1 The interrupt is enabled.
10-9 REG1AP Region 1 access permission. These bits determine the access permission for region 3.
0 All accesses are allowed.
1h Read only accesses are allowed.
2h Write only accesses are allowed.
3h No accesses are allowed.
8 REG1ENA Region 1 enable.
0 The region is disabled (no address checking done).
1 The region is enabled (address and access permission checking done).
7-5 Reserved 0 Reads return zeros and writes have no effect.
4 INT0AB Interrupt assignment of region 0 to Group A or Group B.
0 The interrupt is routed to the VIM (Group A).
1 The interrupt is routed to the second CPU (Group B).
3 INT0ENA Interrupt enable of region 0.
0 The interrupt is disabled.
1 The interrupt is enabled.
2-1 REG0AP Region 0 access permission. These bits determine the access permission for region 0.
0 All accesses are allowed.
1h Read only accesses are allowed.
2h Write only accesses are allowed.
3h No accesses are allowed.
0 REG0ENA Region 0 enable.
0 The region is disabled (no address checking done).
1 The region is enabled (address and access permission checking done).
