Control Registers and Control Packets
www.ti.com
770
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
Direct Memory Access Controller (DMA) Module
20.3.1.65 DMA Memory Protection Status Register 1 (DMAMPST1)
Figure 20-82. DMA Memory Protection Status Register 1 (DMAMPST1) [offset = 1B4h]
31 25 24 23 17 16
Reserved REG3FT Reserved REG2FT
R-0 R/W1C-0 R-0 R/W1C-0
15 9 8 7 1 0
Reserved REG1FT Reserved REG0FT
R-0 R/W1C-0 R-0 R/W1C-0
LEGEND: R/W = Read/Write; R = Read only; W1C = Write 1 to clear; -n = value after reset
Table 20-72. DMA Memory Protection Status Register 1 (DMAMPST1) Field Descriptions
Bit Field Value Description
31-25 Reserved 0 Reads return 0. Writes have no effect.
24 REG3FT Region 3 fault. This bit determines whether an access permission violation was detected in this region.
0 Read: No fault was detected.
Write: No effect.
1 Read: A fault was detected.
Write: The bit was cleared.
23-17 Reserved 0 Reads return 0. Writes have no effect.
16 REG2FT Region 2 fault. This bit determines whether a access permission violation was detected in this region.
0 Read: No fault was detected.
Write: No effect.
1 Read: A fault was detected.
Write: The bit was cleared.
15-9 Reserved 0 Reads return 0. Writes have no effect.
8 REG1FT Region 1 fault. This bit determines whether an access permission violation was detected in this region.
0 Read: No fault was detected.
Write: No effect.
1 Read: A fault was detected.
Write: The bit was cleared.
7-1 Reserved 0 Reads return 0. Writes have no effect.
0 REG0FT Region 0 fault. This bit determines whether a access permission violation was detected in this region.
0 Read: No fault was detected.
Write: No effect.
1 Read: A fault was detected.
Write: The bit was cleared.
