Analog To Digital Converter (ADC) Module
22.3.22 ADC Group2 DMA Control Register (ADG2DMACR)
ADC Group2 DMA Control Register (ADG2DMACR) is shown in Figure 22-44 and described in Table 22-
28.
Figure 22-44. ADC Group2 DMA Control Register (ADG2DMACR) [offset = 54h]
31 25 24 16
Reserved G2_BLOCKS
R-0 R/W-0
15 8
Reserved
R-0
7 4 3 2 1 0
Reserved DMA_G2_END G2_BLK_XFER Reserved G2_DMA_EN
R-0 R/W-0 R/W-0 R-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 22-28. ADC Group2 DMA Control Register (ADG2DMACR) Field Descriptions
Bit Field Value Description
31-25 Reserved 0 Reads return 0. Writes have no effect.
24-16 G2_BLOCKS Number of Group2 Result buffers to be transferred using DMA if the ADC module is configured
to generate a DMA request. If the Group2 is configured to use the block transfer mode of the
DMA module, then the ADC module generates a DMA request after the Group2 results’
memory accumulates G2_BLOCKS number of conversion results.
This feature is designed to be used in place of the threshold interrupt for the Group2. As a
result, the G2_THR field of the Group2 Interrupt Threshold Control Register and the G2
BLOCKS field of the Group2 DMA Control Register are the same.
Any operation mode read/write:
0 No DMA transfer occurs even if G2_BLK_XFER is set to 1.
1h-1FFh One DMA request is generated if the G2_BLK_XFER is set to 1 and the specified number of
Group2 conversion results have been accumulated.
15-4 Reserved 0 Reads return 0. Writes have no effect.
3 DMA_G2_END Group2 Conversion End DMA Transfer Enable.
Any operation mode read:
0 ADC module generates a DMA request for each write to the group2 results RAM if
G2_DMA_EN is set.
1 ADC module generates a DMA request when the ADC has completed the conversions for all
channels selected for conversion in the group2.
If DMA_G2_END bit is set to 1, G2_DMA_EN bit is ignored and DMA requests will be
generated every time the DMA_G2_END flag in the group 2 status register is set. The
DMA_G2_END bit must be set before enabling conversions for the group 2.
2 G2_BLK_XFER Group2 Block DMA Transfer Enable.
Any operation mode read:
0 ADC module generates a DMA request for each write to the Group2 memory if G2_DMA_EN is
set.
1 ADC module generates a DMA request when the ADC has written G2_BLOCKS number of
buffers into the Group2 memory.
If G2_BLK_XFER bit is set to 1, G2_DMA_EN bit is ignored and DMA requests will be
generated every time the Threshold Counter reaches 0 from a count value of 1.
1 Reserved 0 Reads return 0. Writes have no effect.
