Analog To Digital Converter (ADC) Module
Table 22-27. ADC Group1 DMA Control Register (ADG1DMACR) Field Descriptions (continued)
Bit Field Value Description
0 G1_DMA_EN Group1 DMA Transfer Enable.
Any operation mode read:
0 ADC module does not generate a DMA request when it writes the conversion result to the
Group1 memory.
1 ADC module generates a DMA transfer when the ADC has written to the Group1 memory. The
G1_BLK_XFER bit must be cleared to 0 for this DMA request to be generated.
