www.ti.com
FlexRay Module Registers
1313
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
FlexRay Module
Figure 26-86. Clear on Event to System Memory Set 3 (CESMS3) [offset_TU = F0h]
31 16
CESMS3[95-80]
R/WS-0
15 0
CESMS3[79-64]
R/WS-0
LEGEND: R/W = Read/Write; R = Read only; S = Set; -n = value after reset
Table 26-66. Clear on Event to System Memory Set 3 (CESMS3) Field Descriptions
Bit Field Value Description
31-0 CESMS3[n] Clear on Event to System Memory Set 3. The register bits 0 to 31 correspond to message buffers
64 to 95. Each bit of the register enables an automatic clear of the corresponding ETESM3 bit after
a receive or transmit event:
0 No clear.
1 Activate clear.
Figure 26-87. Clear on Event to System Memory Reset 3 (CESMR3) [offset_TU = F4h]
31 16
CESMR3
R/WC-0
15 0
CESMR3
R/WC-0
LEGEND: R/W = Read/Write; R = Read only; C = Clear; -n = value after reset
Table 26-67. Clear on Event to System Memory Reset 3 (CESMR3) Field Descriptions
Bit Field Description
31-0 CESMR3 Clear on Event to System Memory Reset 3. The CESMR3 register shows the identical values to CESMS3 if
read.
