FlexRay Module Registers
1321
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
FlexRay Module
Figure 26-102. Transfer to Communication Controller Interrupt Enable Set 3 (TCCIES3)
[offset_TU = 130h]
31 16
TCCIES3[95-80]
R/WS-0
15 0
TCCIES3[79-64]
R/WS-0
LEGEND: R/W = Read/Write; R = Read only; S = Set; -n = value after reset
Table 26-82. Transfer to Communication Controller Interrupt Enable Set 3 (TCCIES3)
Field Descriptions
Bit Field Value Description
31-0 TCCIES3[n] Transfer to Communication Controller Interrupt Enable Set 3. The register bits 0 to 31 correspond
to message buffers 64 to 95. Each bit of the register enables a potential interrupt, which occurs if
the corresponding TCCO3 bit is set:
0 No interrupt.
1 Interrupt is generated.
Figure 26-103. Transfer to Communication Controller Interrupt Enable Reset 3 (TCCIER3)
[offset_TU = 134h]
31 16
TCCIER3
R/WC-0
15 0
TCCIER3
R/WC-0
LEGEND: R/W = Read/Write; R = Read only; C = Clear; -n = value after reset
Table 26-83. Transfer to Communication Controller Interrupt Enable Reset 3 (TCCIER3)
Field Descriptions
Bit Field Description
31-0 TCCIER3 Transfer to Communication Controller Interrupt Enable Reset 3. The TCCIER3 register shows the identical
values to TCCIES3 if read.
