FlexRay Module
Figure 26-104. Transfer to Communication Controller Interrupt Enable Set 4 (TCCIES4)
[offset_TU = 138h]
31 16
TCCIES4[127-112]
R/WS-0
15 0
TCCIES4[111-96]
R/WS-0
LEGEND: R/W = Read/Write; R = Read only; S = Set; -n = value after reset
Table 26-84. Transfer to Communication Controller Interrupt Enable Set 4 (TCCIES4)
Field Descriptions
Bit Field Value Description
31-0 TCCIES4[n] Transfer to Communication Controller Interrupt Enable Set 4. The register bits 0 to 31 correspond
to message buffers 96 to 127. Each bit of the register enables a potential interrupt, which occurs if
the corresponding TCCO4 bit is set:
0 No interrupt.
1 Interrupt is generated.
Figure 26-105. Transfer to Communication Controller Interrupt Enable Reset 4 (TCCIER4)
[offset_TU = 13Ch]
31 16
TCCIER4
R/WC-0
15 0
TCCIER4
R/WC-0
LEGEND: R/W = Read/Write; R = Read only; C = Clear; -n = value after reset
Table 26-85. Transfer to Communication Controller Interrupt Enable Reset 4 (TCCIER4)
Field Descriptions
Bit Field Description
31-0 TCCIER4 Transfer to Communication Controller Interrupt Enable Reset 4. The TCCIER4 register shows the identical
values to TCCIES4 if read.
