FlexRay Module Registers

1333

SPNU563A–March 2018

Submit Documentation Feedback

FlexRay Module

Table 26-92. Single-Bit Error Status Register (SBESTAT) Field Descriptions (continued)

Bit Field Value Description

3 STBF1 ECC single-bit error in transient buffer RAM A.

0 No ECC single-bit error.

1 ECC single-bit error occurred when reading transient buffer RAM A.

2 SMR ECC single-bit error in message RAM.

0 No ECC single-bit error.

1 ECC single-bit error occurred when reading message RAM.

1 SOBF ECC single-bit error in output buffer RAM 1, 2.

0 No ECC single-bit error.

1 ECC single-bit error occurred when message handler read output buffer RAM 1,2.

0 SIBF ECC single-bit error in input buffer RAM 1, 2.

0 No ECC single-bit error.

1 ECC single-bit error occurred when message handler read input buffer RAM 1,2.
