FlexRay Module Registers

www.ti.com

1404

SPNU563A–March 2018

Submit Documentation Feedback

FlexRay Module

26.3.2.8.4 Write Header Section Register 3 (WRHS3)

Figure 26-183 and Table 26-156 illustrate this register.

Figure 26-183. Write Header Section Register 3 (WRHS3) [offset_CC = 508h]

31 16

Reserved

R-0

15 11 10 0

Reserved DP

R-0 R/W-0

LEGEND: R/W = Read/Write; R = Read only; -n = value after reset

Table 26-156. Write Header Section Register 3 (WRHS3) Field Descriptions

Bit Field Value Description

31-11 Reserved 0 Reads return 0. Writes have no effect.

10-0 DP 1-7FFh Data pointer. Pointer to the first 32-bit word of the data section of the addressed message buffer in

the message RAM.
