Multi-Buffered Serial Peripheral Interface Module (MibSPI) with Parallel Pin

Option (MibSPIP)

28.2.6.6.3 Parallel Mode Pin Mapping, MSB-First, LSB-First

Table 28-6 and Table 28-7 describe the SIMO and SOMI pin mapping when SPI is used in parallel mode

(1, 2, 4, 8) pin mode, LSB first.

Table 28-6. Pin Mapping for SIMO Pin with LSB First

Parallel Mode Shift Register Bit SIMO[7:0]

1 0 0

2 8 1

0 0

4 12 3

8 2

4 1

0 0

8 14 7

12 6

10 5

8 4

6 3

4 2

2 1

0 0

Table 28-7. Pin Mapping for SOMI Pin with LSB First

Parallel Mode Shift Register Bit SOMI[7:0]

1 15 0

2 7 0

15 1

4 3 0

7 1

11 2

15 3

8 1 0

3 1

5 2

7 3

9 4

11 5

13 6

15 7
