Basic Operation

1521

SPNU563A–March 2018

Submit Documentation Feedback

Multi-Buffered Serial Peripheral Interface Module (MibSPI) with Parallel Pin

Option (MibSPIP)

28.2.6.6.2 Parallel Mode Pin Mapping, MSB First

Table 28-4 and Table 28-5 describe the SOMI and SIMO pin mapping when the SPI is used in parallel

mode (1, 2, 4, 8) pin mode, MSB first.

NOTE: MSB-first or LSB-first can be configured using the SHIFTDIRx bit of the SPIFMTx registers.

Table 28-4. Pin Mapping for SIMO Pin with MSB First

Parallel Mode Shift Register Bit SIMO[7:0]

1 15 0

2 15 1

7 0

4 15 3

11 2

7 1

3 0

8 15 7

13 6

11 5

9 4

7 3

5 2

3 1

1 0

Table 28-5. Pin Mapping for SOMI Pin with MSB First

Parallel Mode Shift Register Bit SOMI[7:0]

1 0 0

2 0 0

8 1

4 0 0

4 1

8 2

12 3

8 0 0

2 1

4 2

6 3

8 4

10 5

12 6

14 7
