SCI/LIN Control Registers

www.ti.com

1668

SPNU563A–March 2018

Submit Documentation Feedback

Serial Communication Interface (SCI)/ Local Interconnect Network (LIN)

Module

29.7.1 SCI Global Control Register 0 (SCIGCR0)

The SCIGCR0 register defines the module reset. Figure 29-28 and Table 29-11 illustrate this register.

Figure 29-28. SCI Global Control Register 0 (SCIGCR0) (offset = 00)

31 16

Reserved

R-0

15 1 0

Reserved RESET

R-0 R/WP-0

LEGEND: R = Read only; R/WP = Read/Write in privileged mode only; -n = value after reset

Table 29-11. SCI Global Control Register 0 (SCIGCR0) Field Descriptions

Bit Field Value Description

31-1 Reserved 0 Reads return 0. Writes have no effect.

0 RESET This bit resets the SCI/LIN module. This bit is effective in SCI and LIN mode.

0 SCI/LIN module is in reset.

1 SCI/LIN module is out of reset.

Note: Read/Write in privileged mode only.
