Serial Communication Interface (SCI)/ Local Interconnect Network (LIN)
Module
29.7 SCI/LIN Control Registers
The SCI/LIN module registers are based on the SCI registers, with added functionality registers enabled
by the LIN MODE bit in the SCIGCR1 register.
These registers are accessible in 8-, 16-, and 32-bit reads or writes. The SCI/LIN is controlled and
accessed through the registers listed in Table 29-10. Among the features that can be programmed are the
LIN protocol mode, communication and timing modes, baud rate value, frame format, DMA requests, and
interrupt configuration. The base address for the control registers is FFF7 E400h for LIN1/SCI1 and
FFF7 E600h for LIN2/SCI2.
Table 29-10. SCI/LIN Control Registers
Offset Acronym Register Description Section
00h SCIGCR0 SCI Global Control Register 0 Section 29.7.1
04h SCIGCR1 SCI Global Control Register 1 Section 29.7.2
08h SCIGCR2 SCI Global Control Register 2 Section 29.7.3
0Ch SCISETINT SCI Set Interrupt Register Section 29.7.4
10h SCICLEARINT SCI Clear Interrupt Register Section 29.7.5
14h SCISETINTLVL SCI Set Interrupt Level Register Section 29.7.6
18h SCICLEARINTLVL SCI Clear Interrupt Level Register Section 29.7.7
1Ch SCIFLR SCI Flags Register Section 29.7.8
20h SCIINTVECT0 SCI Interrupt Vector Offset 0 Section 29.7.9
24h SCIINTVECT1 SCI Interrupt Vector Offset 1 Section 29.7.10
28h SCIFORMAT SCI Format Control Register Section 29.7.11
2Ch BRS Baud Rate Selection Register Section 29.7.12
30h SCIED Receiver Emulation Data Buffer Section 29.7.13.1
34h SCIRD Receiver Data Buffer Section 29.7.13.2
38h SCITD Transmit Data Buffer Section 29.7.13.3
3Ch SCIPIO0 SCI Pin I/O Control Register 0 Section 29.7.14
40h SCIPIO1 SCI Pin I/O Control Register 1 Section 29.7.15
44h SCIPIO2 SCI Pin I/O Control Register 2 Section 29.7.16
48h SCIPIO3 SCI Pin I/O Control Register 3 Section 29.7.17
4Ch SCIPIO4 SCI Pin I/O Control Register 4 Section 29.7.18
50h SCIPIO5 SCI Pin I/O Control Register 5 Section 29.7.19
54h SCIPIO6 SCI Pin I/O Control Register 6 Section 29.7.20
58h SCIPIO7 SCI Pin I/O Control Register 7 Section 29.7.21
5Ch SCIPIO8 SCI Pin I/O Control Register 8 Section 29.7.22
60h LINCOMPARE LIN Compare Register Section 29.7.23
64h LINRD0 LIN Receive Buffer 0 Register Section 29.7.24
68h LINRD1 LIN Receive Buffer 1 Register Section 29.7.25
6Ch LINMASK LIN Mask Register Section 29.7.26
70h LINID LIN Identification Register Section 29.7.27
74h LINTD0 LIN Transmit Buffer 0 Section 29.7.28
78h LINTD1 LIN Transmit Buffer 1 Section 29.7.29
7Ch MBRS Maximum Baud Rate Selection Register Section 29.7.30
90h IODFTCTRL Input/Output Error Enable Register Section 29.7.31
